FOG LIGHTS - COMPONENT LOCATION

COMPONENT LOCATION

Component code	Description	Reference to the operation
B001	JUNCTION UNIT	Op. 5505A13 ADDITIONAL JUNCTION UNIT IN ENGINE COMPARTMENT - R.R.
B099	MAXI FUSE BOX ON BATTERY	Op. 5530B40 SUPPLY BOX ON BATTERY (LINK BATTERY AND FUSE BOX) - R R
C010	LEFT FRONT EARTH
C015	DASHBOARD EARTH, DRIVER'S SIDE
E050	INSTRUMENT PANEL	Op. 5560B10 CONTROL PANEL - R+R
F015	LEFT FOG LAMP	Op. 5540D10 L/H OR R/H FOG LIGHT (ONE) - R+R
F016	RIGHT FOG LAMP	Op. 5540D10 L/H OR R/H FOG LIGHT (ONE) - R+R
H001	IGNITION SWITCH	Op. 5520A18 IGNITION SWITCH CONTACT CARRIER LOCK BARREL - R.R.
H091	LEFT CONTROL UNIT (PCS, LEFT CONTROL PANEL)	Op. 7040A82 SWITCH UNIT ON LEFT SIDE OF DASHBOARD - R.R.
M001	BODY COMPUTER	Op. 5505A32 BODY COMPUTER - R.R
