Brake lights - component location

Make

Fiat

Model

Grande Punto Factory Service Manual

Year

2005–2012

Section

Exterior lighting › Brake lights - component location

Wiring diagrams and electrical functionsBrake lights - component location

BRAKE LIGHTS - COMPONENT LOCATION

COMPONENT LOCATION

Component code	Description	Reference to the operation
B001	JUNCTION UNIT	Op. 5505A13 ADDITIONAL JUNCTION UNIT IN ENGINE COMPARTMENT - R.R.
B099	MAXI FUSE BOX ON BATTERY	Op. 5530B40 SUPPLY BOX ON BATTERY (LINK BATTERY AND FUSE BOX) - R R
C015	DASHBOARD EARTH, DRIVER'S SIDE
C030	LEFT REAR EARTH
E050	INSTRUMENT PANEL	Op. 5560B10 CONTROL PANEL - R+R
F030	LEFT REAR LIGHT CLUSTER	Op. 5540A44 REAR LIGHT CLUSTER (ONE), LEFT OR RIGHT - R.R.
F031	RIGHT REAR LIGHT CLUSTER	Op. 5540A44 REAR LIGHT CLUSTER (ONE), LEFT OR RIGHT - R.R.
F040	ADDITIONAL REAR LIGHT (THIRD BRAKE LIGHT)	Op. 5550D16 THIRD BRAKE LIGHT - R+R
I030	BRAKE PEDAL SWITCH	Op. 5550D10 BRAKE LIGHT SWITCH - R+R Op. 1060D38 SWITCH ON BRAKE PEDAL - R.R (DIESEL ENGINES)
H001	IGNITION SWITCH	Op. 5520A18 IGNITION SWITCH CONTACT CARRIER LOCK BARREL - R.R.
M001	BODY COMPUTER	Op. 5505A32 BODY COMPUTER - R.R
