D75 Radio phone junction

Make

Fiat

Model

Idea Factory Service Manual

Year

2003–2012

Section

Intermediate couplings › D75 Radio phone junction

Connectors and pin-outsD75 Radio phone junction

D75 Radio phone junction

1.4 16v, 1.3 JTD 16v

Wiring	Colour
20 FACIA	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		BV		P20D	9
3		BN		P20D	8
4		BL		P20D	7
7		LV		D97T	1
8		GV		D97P	3
9	1	RG		D97T	8
10		N		P20D	12
