Introduction (2004 range) (page 4 of 7)

C. Engine type and number.

The marking is stamped on a dedicated plate attached to a lifting ring on the cylinder block and includes the type and serial manufacturing number.

D. Wheels and vehicle production data.

This data is contained on a dedicated plate fitted to the front door pillar on the driver's side.

A. Tyre inflation pressure when empty.

B. Tyre inflation pressure when fully loaded.

C. Tyre size.

D. Rim size.

E. Type of tyre fitted to the vehicle.

F. Vehicle manufacturing date identification code.

G. Available space.

H. Paint code.

I. Vehicle serial manufacturing code.
