TRIP COMPUTER - Location of components
Location of components
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C15 | Facia earth, driver's side | |
| E50 | Instrument panel | 5560B |
| H1 | Ignition switch | 5520A |
| H5 | Stalk unit | 5550A |
| H5 | Steering column switch unit | 5550A |
| M1 | Body computer | 5505A |
| M50 | ABS control unit | 3340A |
| N40 | Fuel level gauge | |
| N40 | Fuel pump and sender unit | 1040A |
| N40 | Fuel pump and sender unit | 1040A |
| N40 | Fuel pump and sender unit | 1040A |
