Fiat Stilo Factory Service Manual (2001-2007)19 · Wiring diagrams and electrical functions
19 · Electrical

CONNECT - Location of components

Make
Fiat
Model
Stilo Factory Service Manual
Year
2001–2007
Section
Instrument panel › CONNECT - Location of components
Wiring diagrams and electrical functionsCONNECT - Location of components

CONNECT - Location of components

Location of components

CONNECT - Location of components

COMPONENTS

Component codeNameAssembly reference
B2Junction unit under dashboard5505A
B99Maxifuse box on battery5530B
C15Facia earth, driver's side
D47Clock spring coupling5580C
D97Short circuiting coupling
H1Ignition switch5520A
M1Body computer5505A
P20Car radio5570T
P20Radio5570T
P25Aerial
