Brake lights wiring diagram
- Make
- Fiat
- Model
- Ulysse Factory Service Manual
- Year
- 2002–2010
- Section
- Exterior lighting › Brake lights wiring diagram
Wiring diagrams and electrical functionsBrake lights wiring diagram
BRAKE LIGHTS WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | Engine compartment junction unit | 5,505A |
| C020 | Passenger dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D085 | Rear/tailgate coupling | |
| F030 | Left rear light cluster | 5540A |
| F031 | Right rear light cluster | 5540A |
| F040 | Additional rear light (third brake light) | 5550D |
| H001 | Ignition switch | 5520A |
| I030 | Brake pedal switch | 5550D |
| M001 | Body computer | 5505A |
