REVERSING LIGHTS COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
A001	BATTERY
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C010	LEFT FRONT EARTH
C011	RIGHT FRONT EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
C030	LEFT REAR EARTH
C031	RIGHT REAR EARTH
F030	LEFT REAR LIGHT CLUSTER	Op. 5540A LIGHTING
F031	RIGHT REAR LIGHT CLUSTER	Op. 5540A LIGHTING
H001	Ignition switch	Op. 5520A IGNITION SWITCH
I020	REVERSING LIGHTS SWITCH	Op. 5050D HEADLAMP WASH/WIPE
L050	AUTOMATIC TRANSMISSION SOLENOID VALVES
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
