Refit Flywheel for 300Tdi Engine Overhaul
ENGINE
50
OVERHAUL
5. Position ring gear to flywheel with square edge
of teeth towards flywheel flange.
6. Press ring gear on to flywheel, allow to air cool.
Flywheel - refit
1. Ensure bolt holes in crankshaft are clean and
dry.
2. Ensure 2 slave 8 mm bolts are screwed fully
into flywheel.
3. Using assistance, position flywheel on
crankshaft.
NOTE: Dowel located.
4. Fit and finger tighten 8 bolts.
5. Restrain crankshaft using tool LRT-12-080
and tighten flywheel bolts by diagonal selection
to 146 Nm.
6. Remove tool LRT-12-080 and crankshaft
pulley.
7. Remove slave bolts from flywheel.
