CAUTION: Prior to disconnecting the fuel

8. Remove rear light unit and release rubber boot 13. Remove six countersunk self-tapping screws from outer panel.
9. Drill out two pop rivets securing rear speaker 14. Remove three bolts securing lower edge of body mounting bracket to body side panel.

CAUTION: Prior to disconnecting the fuel

filler and breather hoses check the level of 15. Working from inside vehicle, remove twenty-one fuel in the tank. Drain as necessary to prevent spillage. 16. Starting from ’BC’ post and working towards rear

10. Working beneath the vehicle, loosen worm drive clips securing filler and breather hoses, and disconnect hoses from tank (RH body side panel only).
11. Disconnect fuel filler negative lead (RH body side panel only). 17. Remove fuel filler pipe (RH panel assembly
12. Remove capping from ’BC’ post, and remove two bolts securing body side panel to ’BC’ post.

securing rear quarter panel to ’E’ post.

side panel at exterior of vehicle; one adjacent to rear mud flap, and two between rear wheel arch and sill finisher.

bolts securing body side panel.

of vehicle, ease outer panel away from body to break seal. When seal strength has been completely broken, push panel towards rear of vehicle to disengage rear quarter panel from ’E’ post. Lift body side and rear quarter panel assembly clear.

only).
