Circuit Qualifiers

IC | Certain abbreviations are used throughout the Electrical Troubleshooting Manual as circuit = | qualifiers. The following list explains all abbreviations used as qualifiers in the Circuit Diagrams.

ABS Anti lock Braking System

LHD Left Hand Drive

RHD Right Hand Drive

LWB Long Wheel Base

SWB Short Wheel Base

NAS North American Countries

MFI-V8 Multiport Fuel Injection (MFI-V8)

MFI-T16 Multiport Fuel Injection (MFI-T16)

300 Tdi Tdi Diesel

300 Tdi with Tdi Diesel with Exhaust Gas EGR Recirculation (EGR)

300 Tdi without Tdi Diesel without Exhaust EGR Gas Recirculation (EGR)

300 Tdi with Tdi Diesel with Electronic

EDC Diesel Control (EDC)

300 Tdi without Tdi Diesel without Elec-

EDC tronic Diesel Control (EDC)

EBl| ELECTRICAL TROUBLESHOOTING MANUAL

Switch Positions

Certain abbreviations are used throughout the Electrical Troubleshooting Manual as Switch Position notes.The following list explains all abbreviations used as Switch Position notes in the Circuit Diagrams.

< 100° Less than 100°

100° More than 100°
