Discovery II
IN CAR ENTERTAINMENT
REPAIRS 86-6-33
Switches - remote control - ICE
$% 86.50.13
Remove
1. Remove the key from the starter switch.
Disconnect both battery leads, negative lead
first. Wait ten minutes before starting work.
2. Remove driver's airbag module.
3. Release remote control switches multiplug and
leads from steering wheel base.
4. Disconnect remote control switches multiplug
from harness.
5. Remove 2 screws securing remote control
switches to steering wheel base.
6. Release and remove remote control switches
from steering wheel.
Refit
1. Fit remote control switches to steering wheel
and secure with screws.
2. Connect remote control switches multiplug to
harness.
3. Secure leads and multiplug to base of steering
wheel.
4. Fit driver's airbag module.
Amplifier - aerial
$% 86.50.29
Remove
1. Remove rear quarter upper trim casing.
REPAIRS, Trim casing - 'D' post.
2. Disconnect coaxial lead and Lucar connector
from amplifier.
3. Disconnect amplifier from aerial.
4. Remove bolt securing amplifier and remove
amplifier.
Refit
1. Position amplifier and secure with bolt.
2. Connect aerial lead, Lucar connector and
coaxial lead.
3. Fit rear quarter upper trim casing.
