Discovery II
IN CAR ENTERTAINMENT
86-6-34 REPAIRS
Speaker - mid range - front door
$% 86.50.34
Remove
1. Remove front door trim casing.
2. Remove locknut securing speaker to front door
trim casing.
3. Remove speaker.
Refit
1. Position speaker and secure to door trim
casing using locknut.
2. Fit front door trim casing.
Speaker - high range - rear door
$% 86.50.35
Remove
1. Remove rear door trim casing.
2. Remove speaker locknut.
3. Remove speaker from door trim casing.
Refit
1. Position speaker and secure withlocknut to
rear door trim casing.
2. Fit rear door trim casing.
