Discovery II
IN CAR ENTERTAINMENT
86-6-32 REPAIRS
Speaker - low/full range - front door
$% 86.50.10
Remove
1. Remove front door trim casing.
2. Remove 10 Torx screws securing front door
pocket to door trim casing.
3. Remove 3 screws securing speaker to door
trim casing.
4. Remove front door speaker.
Refit
1. Position speaker and secure to door trim
casing with screws.
2. Position front door pocket to trim casing and
secure with Torx screws.
3. Fit front door trim casing.
Speaker - low range - rear door
$% 86.50.12
Remove
1. Carefully release 6 clips securing speaker
grille to door trim casing.
2. Remove speaker grille.
3. Remove 3 screws securing rear door speaker
to rear door trim casing.
4. Disconnect multiplug from rear of speaker.
5. Remove speaker.
Refit
1. Position rear door speaker and connect
multiplug.
2. Secure speaker to rear door trim casing with
screws.
3. Position grille to trim casing and secure with
clips.
