Range Rover P38
BMW DIESEL
1
REPAIR
GLOW PLUG CONTROL UNIT
Service repair no - 19.60.33
Remove
1. Disconnect battery negative lead.
2. Remove 2 screws securing ECM housing cover.
Remove cover.
3. Remove 2 harness clamp screws. Remove
harness clamp.
4. Lift ECM and control unit from housing.
5. Remove nut securing battery cable to control
unit. Release cable.
6. Disconnect multiplug. Remove control unit.
Refit
7. Reverse removal procedure.
