Range Rover P38
SUPPLEMENTARY RESTRAINT SYSTEM
3
REPAIR
SRS HARNESS - SINGLE POINT SENSED SYSTEM
Service repair no - 76.73.73
The SRS harness is incorporated into the fascia
harness.
See ELECTRICAL, Repair.
SRS HARNESS - DISTRIBUTED SYSTEM
Service repair no - 76.73.73
Remove
1. Raise the vehicle.
WARNING: Support on safety stands.
2. Remove battery.
See ELECTRICAL, Repair.
3. Remove centre console.
See CHASSIS AND
BODY, Repair.
4. Remove passenger air bag module.
See this
section.
5. Remove radio.
See ELECTRICAL, Repair.
6. Remove instrument pack binnacle.
See
INSTRUMENTS, Repair.
7. Remove 5 screws securing switch pack to
fascia.
8. Disconnect switches, clock and temperature
sensor. Remove switch pack.
9. Remove 4 screws securing heater control panel.
10. Disconnect multiplugs. Remove control panel.
11. Release door aperture seal adjacent to A post
lower trim panels.
12. Driver’s side - LHD automatic vehicles only:
Remove 3 bolts securing foot rest. Remove foot
rest.
