Stop lamps – circuit diagram

Make

Land Rover

Model

Range Rover Classic Electrical Troubleshooting Manual

Year

1995

Section

Circuit diagram › Stop lamps – circuit diagram

Stop lampsStop lamps – circuit diagram

STOP LAMPS – CIRCUIT DIAGRAM

Rear Fog Guard Lamps

Side Lamps

Reversing Lamps

1.5 RY 1.5 RO 1.5 GN

2 3 4

0.7 0.7 R 0.7

[1] [2] [3]

0.7 B

1 C403

1.5 B

S401

See Ground Dis- tribution

E400

E L E C T R I C A L

Stop Lamps H5-2 B

Direction Indica- tor Lamps

1.5 GW 1.5 GP

5 6 C403

0.5 0.7 G

B121 Left Rear Lamp Assembly [4] [5] [1] Rear Fog Lamp [2] Tail Lamp [3] Reverse Lamp [4] Stop Lamp [5] Indicator Lamp
