Range Rover Classic
26
COOLING SYSTEM
RANGE ROVER
2
REPAIR
Refit
6. Reverse removal procedure. Ensuring fan
blades are fitted correctly. Fan is marked
FRONT and should be fitted with word FRONT
closest to radiator. Tighten to
35 Nm.
THERMOSTAT
Service repair no - 26.45.01
Remove
1. Partially drain cooling system, until coolant level
is below thermostat housing.
2. Disconnect hose from thermostat housing.
3. Disconnect electrical connections to water
temperature switch.
4. Remove outlet elbow.
5. Withdraw thermostat.
