Range Rover Classic
ZF
3
FAULT DIAGNOSIS
ROADTEST 3 = CHECKS
12-13-14-15-16-17-18-19-20-21-22-23
D SELECTED FROM REST
LIGHT THROTTLE START
CHECK 12
Check 1st 2nd upshift speed and quality.
CHECK 13
Check 2nd 3rd upshift speed and quality.
CHECK 14
Check 3rd 4th upshift speed and quality.
NOTE: This shift is usually very difficult to
detect but can be confirmed by a 200 rpm
drop in engine speed.
CHECK 15
Check speed and quality of shift into direct drive
clutch, confirmed by 300 rpm drop in engine speed.
NOTE: An intermediate throttle position
engagement of 4th and the direct drive
clutch, which is indicated by a fall of
500rpm in engine speed.
CHECK 16
At approximately 88 kph (55 mph) depress throttle to
kickdown - gearbox should change down to 2nd -
release throttle to re-engage 4th direct drive clutch
continue to accelerate gently.
CHECK 17
At approximately 128 kph (80 mph) depress throttle to
kickdown - gearbox should change down to 3rd -
release throttle to re-engage 4th direct drive clutch
and continue to accelerate gently.
CHECK 18
At approximately 138 kph (85 mph) select 3rd,
gearbox should change immediately down to 3rd.
Release throttle.
CHECK 19
De-accelerate to approximately 47 kph (30 mph)
depress throttle to kickdown - geabox should
downshift to 1st gear, continue accelerating at full
throttle until 3rd gear is attained. To do this you will
have repeated check 2 of Test 1.
CHECK 20
At 128 kph (80 mph) select 2nd no downshift should
occur. Release throttle.
CHECK 21
At 104 kph (65 mph) an automatic downshift into 2nd
gear should occur. Continue to de-accelerate.
CHECK 22
At 88 kph (55 mph) select 1st. No downshift should
occur. Continue to de-accelerate.
CHECK 23
With 1 selected 2nd gear engaged continue to
de-accelerate and at 45 kph (28 mph) the box should
automatically downshift to 1st gear after which no
upshifts will occur in this selector position.
END OF ROADTEST
