Range Rover Classic
SUPPLEMENTARY RESTRAINT SYSTEM
13
REPAIR
Deployment with module removed from vehicle.
Driver’s Airbag Module
These guidelines are written to aid authorised
personnel to carry out the safe disposal of airbag
modules when removed from the vehicle.
WARNING: Only use the LAND ROVER
approved deployment equipment.
Deploy airbag modules in a well ventilated
designated area.
Ensure airbag module is not damaged or ruptured
before deploying.
1. Carry out deployment tool self test.
2. Remove airbag module from steering wheel.
See Driver’s Airbag Module
3. Position tool SMD 4082/2 in vice, ensuring that
vice jaws grip tool above bottom flange to
prevent possibility of tool being forced upwards
from vice. Tighten vice.
WARNING: Ensure tool SMD 4082/1 is not
connected to battery.
4. Secure airbag module to tool SMD 4082/2.
Ensure module is correctly secured using both
fixings.
5. Ensure airbag module mounting brackets are
secure.
