REAR SUSPENSION END BUFFER - REPLACE

Operation 4420W14 · REAR SUSPENSION PROTECTIONS

1.2 8v, 1.3 Multijet, 1.4 16v

Removing

- Position the vehicle on a lift.

- Remove both the rear wheels.

Op. 4450B06 LEFT REAR WHEEL - R.R

Op. 4450B08 RIGHT REAR WHEEL - R.R

Op. 4420A40 L/H OR R/H REAR SUSPENSION COIL SPRING (ONE) - R+R

1. Release the end of travel buffer and remove it.

Refitting

- Fit the new end of travel buffer in place.

Op. 4420A40 L/H OR R/H REAR SUSPENSION COIL SPRING (ONE) - R+R

Op. 4450B06 LEFT REAR WHEEL - R.R

Op. 4450B08 RIGHT REAR WHEEL - R.R

- Remove the vehicle from the lift.
