P053 RIGHT HEATED REAR WINDSCREEN
P053A – Right swing door
| Wiring | Colour |
|---|---|
| See 38 RIGHT SWING DOOR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 1 | N | See D150 RIGHT REAR/RIGHT SWING DOOR COUPLING | 4 | |
P053B – Right swing door
| Wiring | Colour |
|---|---|
| See 38 RIGHT SWING DOOR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 1 | MV | See D150 RIGHT REAR/RIGHT SWING DOOR COUPLING | 3 | |
