P054 left heated rear windscreen
- Make
- Fiat
- Model
- Ducato Factory Service Manual
- Year
- 2002–2006
- Section
- Various consumers › P054 left heated rear windscreen
Connectors and pin-outsP054 left heated rear windscreen
P054 LEFT HEATED REAR WINDSCREEN
P054A – Left swing door
| Wiring | Colour |
|---|---|
| See 39 LEFT SWING DOOR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 1 | N | See D152 LEFT REAR/LEFT SWING DOOR COUPLING | 4 | |
P054B – Left swing door
| Wiring | Colour |
|---|---|
| See 39 LEFT SWING DOOR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 1 | MB | See D152 LEFT REAR/LEFT SWING DOOR COUPLING | 3 | |
