Wiring diagrams and electrical functions BRAKE LIGHTS - Wiring diagram
BRAKE LIGHTS - Wiring diagram
Wiring diagram
COMPONENTS
Component code Name Assembly reference B2 Junction unit under dashboard 5505A B45 Luggage compartment junction unit B99 Maxifuse box on battery 5530B C15 Facia earth, driver's side C30 Left rear earth C31 Rear right earth D6 Front / rear coupling D6 Front/rear coupling E50 Instrument panel 5560B F30 Left rear. light cluster (fixed section) F30 Left rear. light cluster (fixed section) 5540A F30 Left. rear( light cluster on fixed part) F30 Left. rear( light cluster on fixed part) 5540A F31 Right. rear light cluster (fixed part) F31 Right. rear light cluster (fixed part) 5540A F40 Additional ("third brake light") F40 Additional ("third brake light") 5550D F40 Additional ('third brake light') F40 Additional ('third brake light') 5550D H1 Ignition switch 5520A I30 Brake pedal switch M1 Body computer 5505A M50 ABS control unit 3340A M87 (Lato supporto rigido posteriore gruppo motopropulsore) 7.2 ÷ 8.8 M87 (Power unit rigid rear support side 72 88 M87 Cruise-control control unit
Cruise control
Wiring diagram
COMPONENTS
Component code Name Assembly reference B2 Junction unit under dashboard 5505A B45 Luggage compartment junction unit B99 Maxifuse box on battery 5530B C15 Facia earth, driver's side C30 Left rear earth C31 Rear right earth D6 Front / rear coupling D6 Front/rear coupling E50 Instrument panel 5560B F30 Left rear. light cluster (fixed section) F30 Left rear. light cluster (fixed section) 5540A F30 Left. rear( light cluster on fixed part) F30 Left. rear( light cluster on fixed part) 5540A F31 Right. rear light cluster (fixed part) F31 Right. rear light cluster (fixed part) 5540A F40 Additional ("third brake light") F40 Additional ("third brake light") 5550D F40 Additional ('third brake light') F40 Additional ('third brake light') 5550D H1 Ignition switch 5520A I30 Brake pedal switch M1 Body computer 5505A M50 ABS control unit 3340A M87 (Lato supporto rigido posteriore gruppo motopropulsore) 7.2 ÷ 8.8 M87 (Power unit rigid rear support side 72 88 M87 Cruise-control control unit
S.W.
Wiring diagram
COMPONENTS
Component code Name Assembly reference B2 Junction unit under dashboard 5505A B45 Luggage compartment junction unit B99 Maxifuse box on battery 5530B C15 Facia earth, driver's side C30 Left rear earth C31 Rear right earth D6 Front / rear coupling D6 Front/rear coupling E50 Instrument panel 5560B F30 Left rear. light cluster (fixed section) F30 Left rear. light cluster (fixed section) 5540A F30 Left. rear( light cluster on fixed part) F30 Left. rear( light cluster on fixed part) 5540A F31 Right. rear light cluster (fixed part) F31 Right. rear light cluster (fixed part) 5540A F40 Additional ("third brake light") F40 Additional ("third brake light") 5550D F40 Additional ('third brake light') F40 Additional ('third brake light') 5550D H1 Ignition switch 5520A I30 Brake pedal switch M1 Body computer 5505A M50 ABS control unit 3340A M87 (Lato supporto rigido posteriore gruppo motopropulsore) 7.2 ÷ 8.8 M87 (Power unit rigid rear support side 72 88 M87 Cruise-control control unit
19 Electrical
