FOG LIGHTS - Wiring diagram
- Make
- Fiat
- Model
- Stilo Factory Service Manual
- Year
- 2001–2007
- Section
- Interior lighting › FOG LIGHTS - Wiring diagram
Wiring diagrams and electrical functionsFOG LIGHTS - Wiring diagram
FOG LIGHTS - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C10 | Front left earth | |
| C11 | Right front earth | |
| C15 | Facia earth, driver's side | |
| E50 | Instrument panel | 5560B |
| F10 | Left headlamp | 5540B |
| F11 | Right headlamp | 5540B |
| H1 | Ignition switch | 5520A |
| H90 | Switch control unit | 7040A |
| M1 | Body computer | 5505A |
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C10 | Front left earth | |
| C11 | Right front earth | |
| C15 | Facia earth, driver's side | |
| E50 | Instrument panel | 5560B |
| F10 | Left headlamp | 5540B |
| F11 | Right headlamp | 5540B |
| H1 | Ignition switch | 5520A |
| H90 | Switch control unit | 7040A |
| M1 | Body computer | 5505A |
