Discovery II
ENGINE - V8
12-2-48 OVERHAUL
21. Position alternator cables and tighten terminal
B+ to 18 Nm (13 lbf.ft) and terminal D+ to 5 Nm
(3.5 lbf.ft).
22. Position auxiliary housing, fit bolts and tighten
to 40 Nm (30 lbf.ft). Fit nut and tighten to 22 Nm
(17 lbf.ft).
23. Clean jockey pulley mating faces.
24. Position jockey pulley and tighten bolt to 50 Nm
(37 lbf.ft).
25. Clean PAS pump pulley mating faces.
26. Position PAS pump pulley, fit bolts and tighten
to 22 Nm (17 lbf.ft).
27. Secure injector harness and connect injector
multiplugs.
28. Connect multiplug to coolant thermistor.
Gasket - exhaust manifold
$% 30.15.12.01
Disassembly
1. Remove 8 bolts securing exhaust manifold and
collect spacers. Discard the bolts.
2. Remove exhaust manifold.
3. Remove 2 manifold gaskets and discard.
Reassembly
1. Clean exhaust manifold and cylinder head
mating face.
CAUTION: Do not use a metal scraper or
machined surfaces may be damaged.
2. Fit new gaskets, dry, fit exhaust manifold.
CAUTION: Ensure that link bar on gasket is
positioned below spark plugs.
LH bank illustrated
3. Fit spacers to new manifold bolts and, working
in the sequence illustrated, initially tighten bolts
to 15 Nm (11 lbf.ft), then finally tighten to 38 Nm
(28 lbf.ft).
