Discovery II
GENERAL DATA
04-19
Brakes
Type
Servo assisted, diagonally split hydraulic on outboard discs, with four
channel electronic control ABS
Disc diameter:
⇒
Front
297.0 - 297.4 mm (11.693 - 11.709 in)
⇒
Rear
303.8 - 304.2 mm (11.961 - 11.976 in)
Front disc minimum thickness:
⇒
New
24.9 - 25.1 mm (0.980 – 0.988 in)
⇒
Service limit
22.0 mm (0.866 in)
Rear disc minimum thickness:
⇒
New
12.5 – 12.7 mm (0.492 – 0.500 in)
⇒
Service limit
11.7 mm (0.461 in)
Maximum disc runout
0.15 mm (0.006 in)
Minimum pad material thickness
2.0 mm (0.079 in)
Handbrake
Cable operated drum on transfer box rear output shaft
