Discovery II
GENERAL DATA
04-20
Wheels and tyres
CAUTION: When towing, the additional load imposed may cause the tyre maximum load rating to be
exceeded. This is permissible provided the load rating is not exceeded by more than 15% and that road
speeds are limited to 62 mph (100 km/h) and tyres pressures are increased by at least 3 lbf/in
2
(0.2 bar).
NOTE: The tyre size is displayed on the outer wall of each tyre.
Normal operating conditions: carrying up to 4 passengers and luggage.
Wheel size:
⇒
Steel
7J x 16
⇒
Alloy
7J x 16
8J x 16
8J x 18
Tyre size
⇒
With 7J x 16 wheels
235/70 R16 Wrangler HP 105H
235/70 R16 Michelin XPC * 105H
⇒
With 8J x 16 wheels
255/65 R16 Wrangler HP 109H
255/65 R16 Michelin XPC * 109H
⇒
With 8J x 18 wheels
255/55 R18 Wrangler HP 109H
Tyre Pressures
All tyres - normal operating conditions
Front
Up to 03MY - 1.9 Bar (28 lbf.in
2
)
From 03MY - 2.1 Bar (30 lbf.in
2
)
Rear
2.6 Bar (38 lbf.in
2
)
All tyres - vehicle at GVW
Front
Up to 03MY - 1.9 Bar (28 lbf.in
2
)
From 03MY - 2.1 Bar (30 lbf.in
2
)
Rear
3.2 Bar (46 lbf.in
2
)
