Discovery II: Steering System Overview
GENERAL DATA
04-17
Steering
Note: Measurements taken at EEC kerb weight.
Type
Hydraulically assisted worm and roller
Steering wheel turns lock to lock
3.5
Steering wheel diameter
400 mm (15.7 in)
Turning circle, kerb to kerb
11.9 metres (39.1 feet)
PAS pump
Hobourn Automotive Ltd. Series 500, belt driven
PAS pump pressure - engine at idle with steering at full lock
21 to 62 bar (305 to 900 lbf/in
2
Delivery pressure (nominal)
100 bar (1450 lbf.in
2
) 8.5 litres/min (15.1 pints/min)
(18.1 US pints/min)
Steering geometry:
⇒
Camber angle - Front, up to VIN 2A 754807 - unladen condition
⇒
Camber angle - Front, from VIN 2A 754808 - unladen condition
⇒
Camber angle - Rear - unladen condition
–10'
±
30'
+20'
±
30'
–10'
±
30'
⇒
Cross camber - Front and rear
45' (Maximum)
⇒
Castor angle - unladen condition
3
°
45'
±
45'
⇒
Cross castor
1
°
(Maximum)
⇒
Toe out - Front
⇒
Toe in - Rear
– 0
°
10'
±
0
°
10' (total)
+ 0
°
5'
±
0
°
15' (total)
⇒
Thrust angle
0
°
±
20'
⇒
Swivel pin inclination
13
°
11'
