Discovery II
GENERAL DATA
04-11
Clutch - Td5
Type
Diaphragm spring, hydraulically operated with self-centering,
preloaded release bearing
Drive plate diameter
267 mm (10.5118 in)
Pressure plate diameter
267 mm (10.5118 in)
Clutch plate friction material
Verto F202
Diaphragm finger height when clamped on a 8.5 mm
(0.33 in) thick gauge plate
42.5 to 48.5 mm (1.673 to 1.904 in)
Diaphragm finger clearance (service limit)
1.00 mm (0.040 in)
Clutch plate thickness under 6500 N (1461 lb) axial
load:
⇒
New
8.2 to 8.8 mm (0.33 to 0.34 in)
⇒
Service limit
7.0 mm (0.27 in)
