Discovery II
LIGHTING
REPAIRS
86-2-7
4. Remove 4 screws and remove lamp.
Refit
1. Fit new lamp and secure with screws.
2. For LH lamp:Fit front bumper assembly.
3. For RH lamp: Connect multiplug to harness.
Fit wheel arch liner extension, secure to
bumper valance and liner with screws.
4. Lower vehicle.
Lamp - front fog from 03MY
$% 86.40.96
Remove
1. Remove the front bumper finisher.
Trim finisher - bumper - front - from 03MY.
2. Remove 3 screws securing the fog lamp to the
bumper.
3. Disconnect the fog lamp multiplug and remove
the fog lamp.
Refit
1. Position the fog lamp to the bumper, connect
the multiplug and secure with screws.
2. Fit the front bumper finisher.
