Discovery II
LIGHTING
86-2-6
REPAIRS
Lamp - tail
$% 86.40.70
Remove
1. Remove 4 screws securing tail lamp to body.
2. Disconnect multiplug from tail lamp.
3. Remove tail lamp.
Refit
1. Position tail lamp to body and connect
multiplug.
2. Secure tail lamp to body with screws.
Lamp - front fog up to 03MY
$% 86.40.95
Remove
1. Raise front of vehicle, one side.
2. For RH lamp: Remove 7 screws securing
wheel arch liner extension to liner and bumper
valance and remove liner extension.
Disconnect lamp multiplug from harness.
3. For LH lamp:Remove front bumper assembly.
