Discovery II
LIGHTING
86-2-12 REPAIRS
Rheostat - panel lights dimmer
$% 86.65.37
Remove
1. Remove 2 screws securing instrument cowl to
fascia and release the cowl from the retaining
clips.
2. Disconnect 8 multiplugs from the instrument
cowl switches.
3. Remove the instrument cowl.
4. Remove 2 screws securing the dimmer switch
to the instrument cowl and remove the dimmer
switch.
Refit
1. Fit the dimmer switch to the instrument cowl
and secure with screws.
2. Position the instrument cowl to the fascia and
connect the multiplugs.
3. Fit the instrument cowl to the fascia and secure
with screws.
