ENTERTAINMENT AND INFORMATION SYSTEMSCommon Components · page 2 of 10
ENTERTAINMENT AND INFORMATION SYSTEMS
DESCRIPTION AND OPERATION 86-8-25
Radio Module Harness Connector C0991 Pin Details
Radio Module Harness Connector C1912 Pin Details
Pin No.
Description
Input/Output
1
Not used
–
2
LH and RH audio negative
Input
3 to 7
Not used
–
8
LH audio positive
Input
9
RH audio positive
Input
10
TV RH audio positive
Input
11
TV LH audio positive
Input
12
TV LH and RH audio negative
Input
Pin No.
Description
Input/Output
1
LH audio positive
Input
2
LH audio negative
Input
3 and 4
Not used
–
5
Navigation audio positive
Input
6
Not used
–
7
RH audio positive
Input
8
RH audio negative
Input
9 and 10
Not used
–
11
Navigation audio negative
Input
12
Not used
–
