ENTERTAINMENT AND INFORMATION SYSTEMSCommon Components · page 6 of 10
ENTERTAINMENT AND INFORMATION SYSTEMS
DESCRIPTION AND OPERATION 86-8-29
34
LH front tweeter negative
Output
35 and 36
Not used
–
37
LH rear audio positive
Input
38
LH rear audio positive
Input
39
LH front door mid range speaker negative
Output
40
LH front door mid range speaker positive
Output
41
RH front door mid range speaker negative
Output
42
RH front door mid range speaker positive
Output
Pin No.
Description
Input/Output
