ENTERTAINMENT AND INFORMATION SYSTEMS

DESCRIPTION AND OPERATION 86-8-31

DSP Harness Connector C0492 Pin Details

DSP Harness Connector C0493 Pin Details

Pin No.

Description

Input/Output

1

Not used

–

2

Telephone audio negative

Input

3 and 4

Not used

–

5

I bus

Input/Output

6 and 7

Not used

–

8

RH front audio negative

Input

9

LH front audio negative

Input

10

Not used

–

11

Telephone audio positive

Input

12 to 14

Not used

–

15

Telephone on

Input

16

Not used

–

17

RH front audio positive

Input

18

LH front audio positive

Input

Pin No.

Description

Input/Output

1

LH front door low range speaker positive

Output

2

LH front door low range speaker negative

Output

3

Not used

–

4

RH front door mid range speaker negative

Output

5

LH front door mid range speaker positive

Output

6 to 8

Not used

–

9

RH front door mid range speaker positive

Output

10

LH front door mid range speaker negative

Output

11

RH rear door high range speaker +

Output

12

RH front tweeter positive

Output

13

RH front door low range speaker positive

Output

14

LH front tweeter positive

Output

15

LH front tweeter negative

Output

16

LH rear door high range speaker negative

Output

17 and 18

Not used

–

19

LH rear door high range speaker positive

Output

20 to 23

Not used

–

24

RH rear door high range speaker negative

Output

25

RH front tweeter negative

Output

26

RH front door low range speaker negative

Output
