Common Components (page 10 of 10)

ENTERTAINMENT AND INFORMATION SYSTEMS

DESCRIPTION AND OPERATION 86-8-33

Logic 7 Harness Connector C2416 Pin Details

14

Not connected

–

15

Right front channel (negative)

Input

16

Left front channel (negative)

Input

17

Right rear channel (negative)

Input

18

Left rear channel (negative)

Input

19

Not connected

–

20

Centre fill (negative)

Output

21

Equaliser select

Input

22

Subwoofer (negative)

Output

Pin No.

Description

Input/ output

1

14.4 V

Input

2

14.4 V

Input

3

Right front channel (positive)

Input

4

Left front channel (positive)

Input

5

Sub woofer 1 (positive)

Input

6

Sub woofer 2 (positive)

Input

7

Sub woofer 4 (positive)

Output

8

Sub woofer 2 (positive)

Output

9

Not connected

–

10

Not connected

–

11

Not connected

–

12

Wake up

Input

13

Not used

–

14

Sub woofer 3 (positive)

Output

15

Sub woofer 1 (positive)

Output

16

Right front low range (positive)

Output

17

Left front low range (positive)

Output

18

Right front mid range (positive)

Output

19

Left front mid range (positive)

Output

20

Not used

–

21

Ground

Input

22

Ground

Input

23

Right front (negative)

Input

24

Left front (negative)

Input

25

Sub woofer 1 (negative)

Input

26

Sub woofer 2 (negative)

Input

27

Sub woofer 4 (negative)

Output

28

Sub woofer 2 (negative)

Output

29

Not connected

–

30

Not connected

–

31

Not connected

–

32

Not connected

–

33

Sub woofer 3 (negative)

Output

34

Sub woofer 1 (negative)

Output

35

Right front low range (negative)

Output

36

Left front low range (negative)

Output

37

Right front mid range (negative)

Output

38

Left front mid range (negative)

Output

39

Not connected

–
