L322 Range Rover Service Procedures
ENGINE MANAGEMENT SYSTEM - V8
18-2-14 REPAIRS
Element - air cleaner
$% 19.10.10
Remove
1. Release 2 clips securing MAF/IAT sensor to
upper air cleaner housing. Disconnect SAI
pump air intake hose from upper air cleaner
housing.
2. Release 4 clips and remove upper air cleaner
housing.
3. Discard 'O' ring from upper air cleaner housing.
4. Remove air cleaner element.
Refit
1. Clean air cleaner housing.
2. Fit air cleaner element.
3. Fit 'O' ring seal into upper air cleaner housing.
4. Lubricate 'O' ring.
5. Fit upper air cleaner housing and secure clips.
6. Connect SAI pump hose to upper air cleaner
housing.
