L322 Range Rover Service Procedures
ENGINE MANAGEMENT SYSTEM - V8
18-2-12 REPAIRS
Sensor - temperature - 'E' box
$% 18.30.77
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Disconnect battery earth lead.
2. Remove 10 Allen screws securing 'E' box cover
and remove cover.
3. Disconnect multiplug from 'E' box temperature
sensor.
4. Remove 'E' box temperature sensor.
Refit
1. Fit 'E' box temperature sensor to mounting.
2. Connect multiplug to 'E' box temperature
sensor.
3. Fit 'E' box cover and tighten Allen screws to 2
Nm (1.5 lbf.ft).
4. Connect battery earth lead.
5. If a replacement sensor has been fitted, re-set
adaptions using TestBook/T4.
M18 0726
