TRANSFER BOX

OVERHAUL

47

High/low selector shaft detent

1. Fit detent ball and spring.
2. Apply Loctite 290 to threads of detent plug.
3. Fit and tighten plug then unscrew 2 full turns.
4. Operate high/low selector lever and check that

detent ball can be felt to positively engage and
disengage with grooves in selector shaft; screw
plug in or out until setting is correct.

Interlock solenoid - if fitted

1. Position interlock solenoid in main casing.
2. Apply sealant, Part No. STC 3254 to mating

face of solenoid cover.

3. Fit solenoid cover and Belleville washer, fit

bolts and tighten to 10 Nm (8 lbf.ft).
