Range Rover P38
60
FRONT SUSPENSION
NEW RANGE ROVER
10
REPAIR
DELAY TIMER UNIT
Service repair no - 60.50.46
Remove
1. Raise LH front seat cushion to full extent to
improve access to timer unit.
2. Remove timer unit from terminal block.
Refit
3. Reverse removal procedure.
AIR DRIER
Service repair no - 60.50.09
Remove
WARNING: The air suspension is
pressurised up to 10 bar (150 psi). Dirt or
grease must not enter the system. Wear
hand, ear and eye safety standard protection
when servicing the system.
1. Disconnect 2 pipes from air drier.
2. Seal pipes. Seal drier to prevent moisture
ingress.
3. Remove air drier fixing, remove drier.
Refit
4. Fit drier, tighten fixing to
12 Nm (9 lbf.ft).
5. Remove seals, clean end of pipes.
6. Connect hoses to drier.
7. Leak test connections.
See this section.
