Range Rover P38
77
PANEL REPAIRS
NEW RANGE ROVER
14
REPAIR
LOWER PANEL
Remove
1. Disconnect both battery leads, negative lead
first.
2. Disconnect all ECUs.
3. Disconnect airbags and sensor system.
4. Disconnect alternator.
5. Remove tailgate - lower.
See CHASSIS AND
BODY, Repair.
6. Remove tailgate striker.
See CHASSIS AND
BODY, Repair.
7. Remove rear bumper valance.
See CHASSIS
AND BODY, Repair.
Refit
8. Prepare and clean panel joint faces. Punch or
drill holes in new lower panel for plug welding as
shown.
WARNING: remove ALL traces of adhesive
from joints to quarter panels before plug
welding.
9. Reverse removal procedure.
