Range Rover Classic
GENERAL SPECIFICATION DATA
5
INFORMATION
Lubrication
System
Wet sump, pressure fed
.............................................................................
Pressure, engine warm at normal operating speeds
1.7-3.8 bar (25 - 55 lbf/in
2
)
........
Oil pump:
- Type
Double gear 10 teeth, sintered iron gears
......................................................................
- Drive
Splined shaft from camshaft skew gear
.....................................................................
- End float of both gears
0,026 - 0,135 mm
..........................................
- Radial clearance of gears
0,025 - 0,075 mm
.....................................
- Backlash of gears
0,1 - 0,2 mm
.................................................
Oil pressure relief valve
Non-adjustable
....................................................
Relief valve spring:
- Full length
51.6 mm
.............................................................
- Compressed length at 7.71 kg load
31.0 mm
......................
Oil filter
Screw-on disposable canister
.............................................................................
Engine oil cooler
Combined with coolant radiator and intercooler
...............................................................
