19 - FUEL SYSTEM - TdiEGR CONTROL UNIT
background image

Tdi

9

REPAIR

GLOW PLUG CONTROL UNIT

Service repair no - 19.60.33

Remove

1. Disconnect battery negative lead.

2. Remove nut and bolt securing control unit to

mounting bracket.

3. Disconnect multiplug and remove control unit.

Refit

4. Reverse removal procedure.

EGR CONTROL UNIT

Service repair no - 19.45.06

Remove

1. Release 2 glovebox stays from fascia and pivot

glovebox fully downwards.

2. Remove 2 plastic nuts securing control unit to

body.

3. Release control unit from fixings.
4. Disconnect multiplug and remove control unit.

Refit

5. Reverse removal procedure.
