WHEELS AND TYRES

7

REPAIR

WHEEL STUD

Remove

1. Remove wheel.

See Wheels

2. Drive stud out of driveshaft flange.

Refit

3. Position stud in flange.
4. Install a suitable spacer over stud.
5. Using a M16 x 1.5P nut, a slave wheel nut is

suitable, pull stud into flange until shoulder of
stud abuts flange.

6. Refit wheel.
