InstrumentsCombined coolant temperature gauge and fuel gauge

COMBINED COOLANT TEMPERATURE GAUGE AND FUEL GAUGE

Service repair no - 88.25.16

Remove

  1. Remove printed circuit See this section.
Combined coolant temperature gauge and fuel gauge – Remove printed circuit See this section.
  1. Remove 6 screws securing housing to instrument panel.
  2. Remove instrument housing and release tachometer from housing.
  3. Release retainers, remove window and surround from gauge housing.
  4. Remove gauge from housing.

Refit

  1. Fit gauge to housing.
  2. Fit surround and window to housing.
  3. Fit tachometer to housing.
  4. Fit housing to instrument panel. Fit and tighten screws.
  5. Fit printed circuit. See this section.
