InstrumentsSpeedometer drive cable

SPEEDOMETER DRIVE CABLE

Service repair no - 88.30.06

Remove

  1. Disconnect battery earth lead.
  2. Remove air cleaner. See ENGINE MANAGEMENT SYSTEM - MEMS, Repairs.
  3. Remove radio. See ELECTRICAL, Repairs.
Speedometer drive cable – Remove radio. See ELECTRICAL, Repairs.
  1. Disconnect speedometer cable from rear of instrument pack.
  2. Raise front of vehicle.

WARNING: Support on safety stands.

Speedometer drive cable – Raise front of vehicle.
  1. Loosen knurled nut securing speedometer cable to gearbox.
  2. Release cable grommet from bulkhead.
  3. Release cable and remove from vehicle.

Refit

  1. Fit cable to vehicle.
  2. Connect cable to gearbox and tighten nut.
  3. Connect cable to instrument pack and secure grommet.
  4. Ensure cable is routed correctly and is not kinked or twisted.
  5. Fit radio. See ELECTRICAL, Repairs.
  6. Fit air cleaner. See ENGINE MANAGEMENT SYSTEM - MEMS, Repairs.
  7. Remove stand(s) and lower vehicle.
  8. Connect battery earth lead.
