INSTRUMENT PACK COMPONENTS - REAR VIEW

Instrument pack components - rear view
  1. Panel rear illumination bulbs
  2. Alarm warning indicator led
  3. Direction indicator warning light bulb
  4. Main beam warning light bulb
  5. Catalyst overheat warning light bulb
  6. Seat belt warning light bulb
  7. SRS warning light bulb
  8. ABS warning light bulb
  9. Boot open warning light bulb
  10. Hazard warning light bulb
  11. Brake fail/handbrake warning light bulb
  12. Low oil pressure warning light bulb
  13. Ignition/no charge warning light bulb
  14. Check engine warning light bulb
  15. Rear fog guard warning light bulb
