COURTESY LIGHTS - Wiring diagram
- Make
- Fiat
- Model
- Idea Factory Service Manual
- Year
- 2003–2012
- Section
- Interior lighting › COURTESY LIGHTS - Wiring diagram
Wiring diagrams and electrical functionsCOURTESY LIGHTS - Wiring diagram
COURTESY LIGHTS - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| C20 | Passenger side dashboard earth | |
| C30 | Left rear earth | |
| C31 | Rear right earth | |
| D30 | Rear coupling for /front door. driver's side | |
| D31 | Front passenger door/ rear coupling. | |
| D35 | Rear / rear door coupling left | |
| D36 | Rear/right door coupling right | |
| D42 | Courtesy light coupling | |
| D97 | Short circuiting coupling | |
| E50 | Instrument panel | 5560B |
| G10 | Front courtesy light | 7040E |
| G20 | Rear courtesy light | 7040E |
| G25 | Rear left courtesy light | |
| G26 | Rear right courtesy light | |
| H1 | Ignition switch | 5520A |
| I11 | Boot opening switch | 7015B |
| M1 | Body computer | 5505A |
| M66 | Driver's door control unit | 5505A |
| M67 | Passenger door control unit | |
| N50 | Front driver's door lock geared motor. | 7005A |
| N51 | Passenger front. door lock geared motor | 7005A |
| N55 | Left rear. door lock geared motor | 7010A |
| N56 | Rear door lock geared motor right | 7010A |
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| C20 | Passenger side dashboard earth | |
| C30 | Left rear earth | |
| C31 | Rear right earth | |
| D30 | Rear coupling for /front door. driver's side | |
| D31 | Front passenger door/ rear coupling. | |
| D35 | Rear / rear door coupling left | |
| D36 | Rear/right door coupling right | |
| D42 | Courtesy light coupling | |
| D97 | Short circuiting coupling | |
| E50 | Instrument panel | 5560B |
| G10 | Front courtesy light | 7040E |
| G20 | Rear courtesy light | 7040E |
| G25 | Rear left courtesy light | |
| G26 | Rear right courtesy light | |
| H1 | Ignition switch | 5520A |
| I11 | Boot opening switch | 7015B |
| M1 | Body computer | 5505A |
| M66 | Driver's door control unit | 5505A |
| M67 | Passenger door control unit | |
| N50 | Front driver's door lock geared motor. | 7005A |
| N51 | Passenger front. door lock geared motor | 7005A |
| N55 | Left rear. door lock geared motor | 7010A |
| N56 | Rear door lock geared motor right | 7010A |
