00 Introduction and technical dataBench test
Graph showing engine power curve in CV kW and torque curve in N-m kgm against engine speed in giri/min. 1/min. The power curve peaks around 4000 giri/min at approximately 37 CV, while the torque curve is relatively flat between 2000 and 4000 giri/min, peaking around 75 N-m.

The power curve illustrated can be obtained with the engine overhauled and run in (50 hours of operation) without a fan, with a silencer and air filter fitted at sea level.

BENCH TEST

This test is carried out simply to check that the engine is operating properly in order to carry out any necessary adjustments and check for leaks of oil, coolant or fuel.
